Fuel supply system: TSI Direct Injection
Ignition: Electronic map-controlled ignition
Atmospheric/Supercharged: Turbo charged
Fuel type: ROZ 95
Oil capacity in initial fill (I): 4.3
Alternator (A): 140ME
Battery (Ah/A): 59-70 / 320-420
Acceleration 0-80 km/h (s): 8.2
Acceleration 80-120 km/h (s) at V: 12
Acceleration 1000 m (s): 34.5
Type: 5D
Wheelbase (mm): 2686
In running order with driver (kg): 1260
In running order with driver (kg) Front / Rear: 755 / 505
Maximum weight allowed (kg): 1750
Maximum weight without brake (kg): 630
Maximum weight w/brake 8% (kg): 1300
Maximum weight w/brake 12% (kg): 1100
Gearbox type: MQ200-5F
Ratios I: 3.769
II: 1.947
III: 1.212
IV: 0.881
V: 0.673
VI: -
VII: -
R: 3.640
Group 1 ratio: 4.056
Group 2 ratio: -
Group 3 ratio: -
Speed 1000 rpm in IV/V (km/h): 32.6 / 42.7 / - / -
Rims: 6.5Jx16 ET46 / 7Jx16 ET43 / 7.5Jx17 ET46
Tyres: 205/55 R16 91V / 225/45 R17 91W
Front suspension: Independent McPherson type, coil springs and hydraulic shock absorber
Rear suspension: Semirigid axle, coil springs and hydraulic shock absorber
Steering System: R-EPS (Rack Electric Power System)
Turning diameter (m): 10.5 / 11.2 (between walls)
Brake system: Dual hydraulic circuit and brake system diagonal split with electric brake booster
Type front and rear brakes: Front ventilated disc brakes and rear solid disc brakes
Front brakes (mm): 276x24
Rear brakes (mm): 272x10
TSI Direct Injection
Electronic map-controlled ignition
Turbo charged
ROZ 95
4.3
140ME
59-70 / 320-420
*Provisional data
